LYME SCI: Why persister cells matter with Lyme disease
I recently attended two of Dr. Ying Zhang’s lectures at the International Lyme and Associated Diseases scientific conference in Philadelphia. Dr. Zhang is a professor of molecular microbiology and immunology at the Bloomberg School of Public Health at Johns Hopkins University. He gained international acclaim in the 1990s, when he discovered the mechanisms by which Mycobacterium tuberculosis (TB) develops resistance to two key first-line drugs, isoniazid and pyrazinamide (PZA).
Since then, his research has been pivotal in the treatment of drug-resistant and persistent tuberculosis. In particular, Dr. Zhang’s research on the persister drug PZA has led him to propose the application of the PZA principle to the treatment of persistent infections in general, including Lyme disease.
When Lyme disease symptoms keep going
Over the past several years, Dr. Zhang has applied his extensive knowledge of bacterial resistance and persistence to the biology of Lyme disease. While some patients who are treated early for Lyme improve after a standard course of antibiotics such as doxycycline or amoxicillin, others do not. Many of them go on to experience persistent or recurrent fatigue, pain, numbness, joint and muscle aches, brain fog, or other symptoms.
Patients who receive a late diagnosis of Lyme disease (four or more weeks after infection) have a much greater chance of developing persistent symptoms. Some scientists refer to this as post-treatment Lyme disease syndrome (PTLDS), but patients and the public generally refer to this as “chronic Lyme disease.”
According to surveys by LymeDisease.org, the majority of chronic Lyme patients go two or more years before getting a proper diagnosis.
The Dandelion Phenomenon
While some doctors characterize the residual effects of Lyme disease as the normal “aches and pains of daily living,” Dr. Zhang does not. Rather, he believes that—similar to tuberculosis, syphilis, Q-fever and other infections—the chronic symptoms occur because a short course of antibiotics does not kill all the bacteria, especially persister bacteria.
He likens the use of ineffective antibiotics against bacteria to trying to kill dandelions with a lawnmower. The antibiotics knock out the growing form of the spirochete but not the “persister” forms like the root. Later, just like the weed, the bacteria will grow back and cause relapse.
What Are Persister Cells?
During his ILADS lecture, Zhang outlined several of the potential causes of PTLDS, including autoimmunity, other infections, and persistence. But he focused primarily on “persister cells” not killed by current antibiotics as a contributing factor.
In his 2014 paper, “Persisters, peristent infections and the Yin-Yang model,” Dr. Zhang takes a deep look into more than 70 years of research on persister cells. He has developed a model which describes the ever-changing persistent forms of fungi, parasites, viruses and cancer cells that are involved in long term illness.
Basically, when exposed to hostile environments (immune system or treatment) these invaders will adapt and form variants or mutants that have the ability to go dormant or become resistant. Later when conditions are favorable, the cells will come out of hibernation and cause a resurgence of the illness. Dr. Zhang clearly places Borrelia burgdorferi in the category of bacteria which are prone to developing persister cells.
Zhang feels that to fully understand PTLDS one must understand the peculiar features of the Borrelia spirochete and its variant forms and how this diverse disease expresses itself in response to the immune system. He demonstrated how Borrelia burgdorferi can shape shift from spirochete to round bodies to biofilm.
He reviewed the evidence from several animal studies (Barthold, Hodzic, Embers) where Lyme bacteria are able to persist and resurge up to one year, and also in humans (Marques) despite standard 30-day antibiotic treatment.
Applying TB Science to Lyme Disease
In 2014, Dr. Zhang and his team of researchers at Johns Hopkins developed a technique (SYBR Green/PI viability assay) to test thousands of FDA-approved drugs against Borrelia burgdorferi (Bb), the bacteria that causes Lyme disease.
Using the new test, they were able to determine how many bacteria are alive and how many are dead after being exposed to each drug. Ultimately, they identified 113 drugs that have higher activity against Bb than the standard antibiotics, doxycycline and amoxicillin.
Dr. Zhang discussed his recent research which applies the same principles as TB treatment for the use of combination drugs against persistent Lyme infections. In the 1950s, the recommended treatment for TB was 12-18 months of less effective drugs. However, poor compliance was a serious problem—patients didn’t always take all the medicine they were prescribed.
Furthermore, researchers learned that exposing TB to single drugs readily develops resistance, while using two or more drugs at the same time not only prevented or reduced resistance but also was more effective than single drugs for treating TB. In addition to drug combinations, they found that the length of treatment was important. Among patients given a certain combination of drugs, the relapse rate was 62% for those treated for six months; 19% in those treated for one year, and 4% treated for two years.
Advances in TB therapy over the past 70 years has led to the reduction of treatment time for TB from 18 months to just six months, thanks to the use of persister drugs like PZA. Zhang spent decades to understand how PZA kills persisters and shortens TB therapy, in combination with other drugs that kill growing bacteria, in what he calls the Yin-Yang model.
He found the same principle applies to killing borrelia persisters where the persister drug daptomycin (equivalent of PZA) in combination with doxycycline and cefuroxime has been shown to kill highly resistant biofilm-like microcolony structures in in-vitro studies.
Combination Drugs Are More Effective
In their recent experiments, Zhang’s team applied both single and combination drugs from the FDA drug library. What they discovered is that different drugs act differently against the various forms of Borrelia, and that no single drug is effective in killing all Borrelia persister cells.
Specifically, the current Lyme antibiotics—doxycycline, amoxicillin, cefuroxime, ceftriaxone—have good activity against the growing spirochete, but poor activity against Borrelia persister cells. Even persister drugs such as daptomycin alone, while being more active against persisters than current Lyme antibiotics, could not completely eradicate borrelia persisters.
The team also found that not all drug combinations would work against the borrelia persisters, and the most effective combinations include persister drugs like daptomycin plus doxycycline and cefuroxime. [6,7]
In their most recent study, the researchers also experimented with pulse dosing single and combination drugs. (“Pulse dosing” means giving the drugs on an intermittent schedule—perhaps two days a week—rather than every day.)
They discovered that pulse dosing ceftriaxone but not doxycycline or persister drug daptomycin was effective against the spirochetal and round body forms, but all failed to eradicate Borrelia biofilms.
In the end, they identified the triple-drug combination daptomycin/doxycycline/cefuroxime without pulse dosing, as the most effective way to kill all forms of Borrelia burgdorferi. (I will describe different types of antibiotics and pulse dosing in another post)
Some clinical studies of Lyme treatment have shown little to no improvement in PTLDS symptoms after prolonged use of antibiotics. Zhang speculates that it may be due to using drugs that are active against growing Borrelia bacteria but not against persisters.
He also makes the important distinction that his studies were all done in-vitro, meaning they were conducted in test tubes or culture dishes. Future studies using animal models are needed to validate his findings, eventually followed by testing in humans.
- Perisisters, peristent infections and the Yin-Yang model.
- Xenodiagnosis to Detect Borrelia burgdorferi Infection: A First-in-Human Study
- An optimized SYBR Green I/PI assay for rapid viability assessment and antibiotic susceptibility testing for Borrelia burgdorferi.
- Advances in the Treatment of Tuberculosis
- Identification of novel activity against Borrelia burgdorferi persisters using an FDA approved drug library.
- A Drug Combination Screen Identifies Drugs Active against Amoxicillin-Induced Round Bodies of In Vitro Borrelia burgdorferi Persisters from an FDA Drug Library
- Drug Combinations against Borrelia burgdorferi Persisters In Vitro: Eradication Achieved by Using Daptomycin, Cefoperazone and Doxycycline
- Ceftriaxone Pulse Dosing Fails to Eradicate Biofilm-Like Microcolony B. burgdorferi Persisters Which Are Sterilized by Daptomycin/ Doxycycline/Cefuroxime without Pulse Dosing.
- Persister mechanisms in Borrelia burgdorferi: implications for improved intervention.
LymeSci is written by Lonnie Marcum, a Licensed Physical Therapist and mother of a daughter with Lyme. Follow her on Twitter: @LonnieRhea Email her at: email@example.com .
